Description
| Host Interface | PCIe Gen2 x1 |
| Audio Interface | HDMI (1.3/ HDCP 1.3) |
| Audio Format | PCM |
| Audio Sampling Rate | Audio L/R: 48KHz, 16bit |
| HDMI: 32KHz/44.1KHz/48KHz, 16bit | |
| Connector Type | HDMI |
| VGA | |
| Input Interface | HDMI |
| VGA | |
| Preview Video Format | YUY2 (4:2:2) |
| Record Video Format | AVI: YUY2 (4:2:2) MP4, WMV: YUY2 (4:2:0) |
| Color Depth | 8 bit |
| Channel No. | 1 Ch |
| Max. Input Resolution | 1920 x 1080 60fps |
| Max. Recording Resolution | 1920 x 1080 60fps |
| Encoding Mode | Software encoding |
| Multi-Card Support | No |
| Multi-Channel Support | No |
| Supported OS | Windows 7/8.1/10 (32/64 bits)* |
| Form factor | PCIe Gen2 x1 |
| Dimensions (L x W) | 124.8 x 68.78mm |
| Power requirements | +3.3V max @ 3A |
| +12V max @ 0.5A | |
| Operating Temperature | 0°C ~ 65°C |
| Operating Humidity | 0 ~ 80% Relative humidity |
