Description
| Interface | USB 3.0 |
| Input | HDMI (1.3/ HDCP 1.3) |
| DVI | |
| VGA | |
| Composite / S-Video | |
| SDI | |
| Audio (L/R) | |
| Output | N/A |
| Input Video Resolution
(Note: Signal is considered progressive unless otherwise stated.) |
HDMI (1.3/ HDCP 1.3) |
| DVI | |
| VGA | |
| Any resolution under: a. video width ≦ 1,920 b. video height ≦ 1,200 c. pixel clock < 162MHz |
|
| Composite / S-Video 720×480@60i (NTSC), 720×576@50i (PAL) |
|
| SD-SDI: 720×480@(60i), 720×576@(50i) |
|
| HD-SDI: 1280×720@(50/60), 1920×1080@(50i/60i/24p/25p/30p) |
|
| 3G-SDI: 1920×1080@(50p/60p) |
|
| Capture Video format
(*Captured format is converted to progressive scan) |
640×480, 720×480, 720×576, 800×600, 1024×768, 1280×720, 1280×768, 1280×800, 1280×1024, 1360×768, 1440×900, 1680×1050, 1920×1080, 1920×1200 |
| **There are two options for frame rate (1) The same as input source. (2) Fixd frame rate, range 5~60. |
|
| HW Scaler | Yes |
| Pixel Format | YUY2 (4:2:2) |
| Color Adjustment | Brightness, Contrast, Hue , Saturation |
| Audio Sampling | Audio L/R: 48KHz, 16bit |
| HDMI: 32KHz/44.1KHz/48KHz, 16bit | |
| SDI: 48KHz, 16bits | |
| Multi-Card Support | No |
| Multi-Channel Support | No |
| Crossbar Necessary | Yes |
| Audio Capture Filter Support | Yes |
| HW / SW Encode Support | SW |
| Dimensions (L x W x H) | 218 x 132 x 43mm |
| Supported OS | Windows 7/8.1/10 (32/64 bits)* |
