TS-h1290FX-7302P-128G

$0.00

SKU: TS-h1290FX-7302P-128G Categories: , Tag:

TS-h1290FX-7302P-128G
12-Bay NAS | AMD EPYC™ 7302P 16-core / 32-thread 3.0 GHz processor (up to 3.3 GHz)
RAM: 128GB DDR4 RDIMM ECC RAM (8 x 16GB) | MAX RAM: 1TB DDR4 RDIMM ECC RAM (8 x 128GB) | 5GB DOM (Dual boot OS protection)
Internal Storage: 12 x 2.5″ U.2 NVMe Gen4 x4
External Ports: 3 x USB 3.2 Gen1
GbE Ports: 2 x 2.5GbE (RJ45) , 2 x 25GbE (SFP28, with iSER Support)
PCI-E Slots: 3 x PCIe Slot x16 (Gen4), 1 x PCIe Slot x8 (Gen4)
PCI-E Support: QM2 Card / 10G,25G,40G,100G LAN Card / 16G,32G FC Card
OS: QTS / QuTS hero (Pre-Installed)
File System: EXT4 (QTS) / ZFS (QuTS hero), Support Inline Data Deduplication, Compression, Compaction, WORM
RAID Level: RAID 0, 1, 5, 6, 10, 50, 60, TP(QuTS hero), TM(QuTS hero), JBOD | Support QTier™ Auto Tiering (QTS)
Surveillance Station: N/A | QVR Elite: 2 x IP Cam Licenses | QVR Pro: 8 x IP Cam Licenses (QTS)
5 Years Carry-In Warranty (Optional: Upgrade to Onsite Warranty)

Description

CPU AMD EPYC™ 7232P/7252 8-core/16-thread processor, up to 3.2 GHz
CPU Architecture 64-bit x86
Encryption Engine  (AES-NI)
System Memory 64 GB RDIMM DDR4 ECC (8 x 8 GB)
Maximum Memory 1 TB (8 x 128 GB)
Memory Slot 8 x RDIMM DDR4
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 12 x 2.5-inch

The system is shipped without SSD.
For the SSD compatibility list, please visit https://www.qnap.com/compatibility/
Drive Compatibility 2.5-inch bays:
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch U.2 NVMe PCIe Gen4 x4 solid state drives
Hot-swappable
SSD Cache Acceleration Support
GPU pass-through
SR-IOV
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M/10M)
25 Gigabit Ethernet Port 2 x 25GbE SFP28 SmartNIC port
Jumbo Frame
PCIe Slot 4
Slot 1: PCIe Gen 4 x16
Slot 2: PCIe Gen 4 x16
Slot 3: PCIe Gen 4 x8
Slot 4: PCIe Gen 4 x16
USB 3.2 Gen 1 port 3
Form Factor Tower
LED Indicators Power/Status, LAN, USB, SSD1-12
LCD Display/ Button
Buttons Power, Reset, USB Auto Copy
Dimensions (HxWxD) 5.91 × 14.49 × 14.25 inch
Weight (Net) 19.82 lbs
Operating Temperature 0 – 40 °C (32°F – 104°F)
Storage Temperature -20 – 70°C (-4°F – 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 750W, 100-240V
Power Consumption: Operating Mode, Typical 134.41 W
Fan 2 x 92mm, 12VDC
System Warning Buzzer
Kensington Security Slot
Max. Number of Concurrent Connections (CIFS) – with Max. Memory 10,000
